24FJ128GA202-ISP - MCU, PICmicro, 16-bit, 128 KB, SPDIP-28

PIC24F 16-bit Microcontroller featuring integrated Hardware Crypto module and eXtreme Low Power. This family also includes 128KB flash, 8KB RAM and advanced peripherals. The combination of features makes the part ideally suited for low power embedded security applications.• AES Engine with 128,192 or 256-Bit Key• Supports ECB, CBC, OFB, CTR and CFB128 modes• DES/Triple DES (TDES) Engine: Supports 2-Key and 3-Key EDE or DED TDES• Supports up to Three Unique Keys for TDES• Programmatically Secure• True Random Number Generator• Pseudorandom Number Generator• Non-Readable, On-Chip, OTP Key Storages Technical Data: Architecture: 16-bitCPU Speed (MIPS): 16Memory Type: FlashProgram Memory (KB): 128RAM Bytes: 8,192Temperature Range: -40 ... +85°COperating Voltage Range: 2 ... 3.6 VI/O Pins: 20Pin Count: 28Internal Oscillator: 8 MHzDigital Communication Peripherals: 4-UART, 3-SPI, 2-I2CCodec Interface: YesComparators: 3Timers: 5 x 16-bit 2 x 32-bit
